BUBBLE AND FOAM INSULATION
Aluminium Foil Insulation made from the finest raw materials and are manufactured with high technology, making Aluminium Foil Insulation is a product of good quality.
By using material that is safe for healthy (non allergic fiber) that does not cause allergies and cancer, and high-quality aluminium material that reflects infrared heat energy and make all products have a good performance in energy efficiency
GENERAL SPECIFICATION
FOIL REFLECTIVITY
FOIL PURITY
ROLL SIZE
PLIABILITY
FUNGI GROWTH ABILITY
HEALTH AND SAFETY
96,97%
99,45%
1,2 m x 25 m ( 30 m2)
No cracking
NIL
Non-Fibrous / Non-Itchy / Non Toxic
Non Carcinogenic & Non Allergenic
INSTALLATION GUIDELINES
TILED AND METAL RESIDENTIAL ROOFS
o Starting at the gutter, roll out the foil across the rafters and ensuring a 50mm overlap into the gutter is achieved.
o Fix to rafters, allow 150 mm with end joins overlapped by rafter spacing (600 mm for metal roof) if not taped
o Fix Battens as per roof cover requirements and applicable standards
METAL COMMERCIAL / WAREHOUSE ROOFS
o Starting at the gutter, roll out the foil across the rafters and ensuring a 50mm overlap into the gutter is achieved.
o Allow 40mm sag between purlins, installed loosely if using a mesh to allow the sag.
o Overlap by 50mm at joins and apply 72 to 100mm reinforced foil tape to top of join.
o Overlap by 600mm end join if not taped.
o Fix roof sheeting by screwing through foil to the purlins
